Home  > Haida Products  > Paper Packaging Test Equipment  > Compression Test Equipment  >  Microcomputer type carton compressive tester HD-A502S-1500

Haida Equiment Manufacturer

Haida Equiment Manufacturer has more than 10 years experience for test equipment...

Microcomputer type carton compressive tester HD-A502S-1500

Microcomputer type carton compressive tester HD-A502S-1500

Minimum
1 SET
Delivery
15 days after order.
Model
HD-A502S-1500
Country
China
BrandName
HD
Package
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Payment
L/C, D/P, T/T
Price
FOB, CIF

Microcomputer type carton compressive tester HD-A502S-1500


Carton Compressive Tester Video                               Carton Compressive Tester Brochure


Specifications

Concrete Compressive Strength Tester Price
1.Motor:Import servo motor
2.Control system:Computer control


1. The Application:

Concrete Compressive Strength Tester Price  used for measuring the pressure strength of cartons, containers, etc. for inspecting the pressure-resistance and strike-endurance of packing materials during transportation or carry. It's equipped with 4 precise Load Cells for detection. The testing results are displayed by computer.


2.Specifications


Concrete Compressive Strength Tester Price

Model

HD-A502S-1500

Capacity (optional)

1000KG,1000KG,1200KG

Unit (switchable)

Kg, Lb, N

Load Resolution

1/250,000

Load Accuracy

 ≤0.5%

Stroke (exclude the grips)

400 mm

Test Space (L×W×H)

130000×1500×1200mm

Speed of Compression

10 ± 3 mm/min

Operation Mode

PC

Report Items

Serial number, Peak value, Average value, Designated holding pressure value; all memorable

Structure

Panasonic servo Motor (Japan) ; Imported ball screw rod

Dimension (L×W×H)

2000×1500×2030mm

Weight

Approx. 1340kg

Power

1ø, 220v/ 50Hz

Safety Devices

Overload protection, overvoltage protection & limited position protection device

Standard

TAPPI-T804, JIS-20212, GB4857.3.4, ASTM-D642



 3.The Features:

Concrete Compressive Strength Tester Price

 1. Adopting windows platform, and all the parameter settings can be processed in the dialog box, and it operates easily;
2. Using a single-screen operation; do not need to switch the screen;
3. With three languages in Simplified Chinese, Traditional Chinese and English, the software interface can be switched easily;
4. The pattern of Test reports can be self-designated; test data can be displayed directly in the main screen;
5. Choosing translational, comparative mode at the same time to make a number of curve data comparison;
6. With a variety of measurement units, Measure In Imperial & Metric are switchable;
7. With self-return & auto-correction function;
8. With automatic magnification function, in order to achieve the most appropriate size of the graphics;
9. With the user-defined Test methods; with experimental data analysis function;
10. It can do test of compression, bending, pressure holding & fatigue.
11. With high precision and accuracy and reasonable price, it can test the crush instantaneously and stop automatically.




Company Services:

All Haida employees adhere to the " Quality comes from precision, quality creates the future " business philosophy, serve each client actively and conscientiously in order to satisfy Haida equipment brand consumers' needs.


The certification

ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, SGS, SMC, CMC, CPA, CE,CMA,IMC


The introduction of Haida

Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.
