UV aging test machine

UV aging test machine

Minimum
1 SET
Delivery
15 days after order.
Country
China
BrandName
HD
Package
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Payment
L/C, D/P, T/T
Price
FOB, CIF

UV aging test machine


1. Product description

UV aging test machine which as a kind of environment test chamber can simulate the most important ultraviolet light in the sun, reproduction of light caused by the aging of the physical properties of materials



USAGE:

Environmental Sun Rain Spray Accelerated Weather Testing / UV Testing Machine is mainly used in paint and ink paint, resins, plastics, printing and packaging, aluminum, adhesives, car and motorcycle industry, cosmetics, metals, electronics, electroplating, medicine and other fields. Conform ASTMG53-77 specification GB ﹑ GJB MIL CNS ﹑ ASTM JIS IEC ﹑ Fed Test AATCC DIN ﹑ BS﹑ SAE standards.



2. Technical parameters:

Studio Size

400W×1140D×390Hmm

Outside dimension

500W×1300D×1360Hmm

Materials

Inside and Outside SUS#304 stainless steel

Temperature range

RT+10~70°C

Temperature uniformity

±2°C

Temperature fluctuation

±0.5°C

Temperature control

PID SSR control

Humidity range:

 ≥90%RH

Controller

Korean TEMI 880 programmable controller

Control mode

Balance temperature humidity control (BTHC)

Test cycle setting

Illumination, condensation and water spray
test cycle is programmable

Lamp power

40W/Piece

Distance from sample to lamp

50±2mm (adjustable)

Centre distance between the lamp

70mm

Irradiance

1.0W/cm2

Wavelength ultraviolet light

UV-A: 315-400nm;  UV-B: 280-315nm (8pcs, 1600h lifetime)

Effective irradiation areas

640×1140mm

Irradiation black panel temperature

50°C~70°C

Standard Specimen Size

75×150mm or 75×3000mm
(special specitications to be described in the contact)

Required water depth for water channel

25mm, automatically control

Testing time

0~999H, adjustable

Power

220V/50Hz /±10% 5KW

Protection system

Overload short circuit protection,
over temperature protection, water lackin


Chamber Structure:

The inner bladder of the chamber is made of imported high-class stainless steel plate while the outer bladder is made of SUS 304 steel plate.

The heating mode adopts inner bladder trough type heating with its rapid temperature rise and even temperature distribution.


Design criteria:

 (1) ASTM D4587: Standard Practice for Fluorescent UV-Condensation Exposures of Paint and Related Coatings

(2) ASTM D4799: Standard Practice for Accelerated Weathering Test Conditions and Procedures for Bituminous Materials (Fluorescent UV, Water Spray, and Condensation Method)

(3) ISO 4892-1: Plastics – Methods of Exposure to Laboratory Light Sources – Part 1: General guidance

(4) ISO 4892-3: Plastics - Methods of Exposure to Laboratory Light Sources - Part 3: Fluorescent UV Lamps

(5) ASTM D4329: Standard Practice for Fluorescent UV Exposure of Plastics

(6) AATCC TM186: Weather Resistance: UV Light and Moisture Exposure

(7) ASTM D5208: Standard Practice for Fluorescent Ultraviolet (UV) Exposure of Photodegradable Plastics

(8) IEC 61345: UV Test for Photovaltalic (PV) Modules


Experimental Methods
Method 1: 8 hours of ultraviolet light, a test temperature of 60 degrees, 4 hours condensation, the test temperature of 50 degrees
Method 2: 4 hours of ultraviolet light, a test temperature of 60 degrees, 4 hours condensation, the test temperature of 50 degrees
Method 3: 8 hours of ultraviolet light, a test temperature of 50 degrees, 4 hours condensation, the test temperature of 45 degrees
Method 4: four hours of ultraviolet light, the test temperature is 50 degrees, condensing 4 hours, the test temperature of 45 degrees
Method 5: 1000 hours of ultraviolet light, the test temperature of 60 degrees
Method 6: UV light 300 hours, the test temperature of 80 degrees


Poduct image:

UV aging test machine

UV aging test machine
