Price Concrete Compressive Strength Test Machine 1
Price Concrete Compressive Strength Test Machine 1

Price Concrete Compressive Strength Test Machine

5.0
Model:
HD-A502S-1500
Price:
FOB, CIF
Payment:
L/C, D/P, T/T
Package:
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Delivery:
15 days after order.
design customization

    oops...!

    no product data.

    Go to homepage

    Concrete Compressive Strength Tester Price

    1. The Application:

    Concrete Compressive Strength Tester Price  used for measuring the pressure strength of cartons, containers, etc. for inspecting the pressure-resistance and strike-endurance of packing materials during transportation or carry. It's equipped with 4 precise Load Cells for detection. The testing results are displayed by computer.



    Specifications

    Concrete Compressive Strength Tester Price
    1.Motor:Import servo motor
    2.Control system:Computer control




    2.Specifications



    Concrete Compressive Strength Tester Price

    Model

    HD-A502S-1500

    Capacity (optional)

    5T

    Unit (switchable)

    Kg, Lb, N

    Load Resolution

    1/250,000

    Load Accuracy

     ≤0.5%

    Test Space (L×W×H)

    1300×1500×1200mm

    Speed of Compression

    10 ± 3 mm/min

    Operation Mode

    PC

    Report Items

    Serial number, Peak value, Average value, Designated holding pressure value; all memorable

    Structure

    Panasonic servo Motor (Japan) ; Imported ball screw rod

    Dimension (L×W×H)

    2000×1500×2030mm

    Weight

    Approx. 1340kg

    Power

    1ø, 220v/ 50Hz

    Safety Devices

    Overload protection, overvoltage protection & limited position protection device

    Standard

    TAPPI-T804, JIS-20212, GB4857.3.4, ASTM-D642





     3.The Features:

    Concrete Compressive Strength Tester Price

     1. Adopting windows platform, and all the parameter settings can be processed in the dialog box, and it operates easily;
    2. Using a single-screen operation; do not need to switch the screen;
    3. With three languages in Simplified Chinese, Traditional Chinese and English, the software interface can be switched easily;
    4. The pattern of Test reports can be self-designated; test data can be displayed directly in the main screen;
    5. Choosing translational, comparative mode at the same time to make a number of curve data comparison;
    6. With a variety of measurement units, Measure In Imperial & Metric are switchable;
    7. With self-return & auto-correction function;
    8. With automatic magnification function, in order to achieve the most appropriate size of the graphics;
    9. With the user-defined Test methods; with experimental data analysis function;
    10. It can do test of compression, bending, pressure holding & fatigue.
    11. With high precision and accuracy and reasonable price, it can test the crush instantaneously and stop automatically.



    Company Services:

    All Haida employees adhere to the " Quality comes from precision, quality creates the future " business philosophy, serve each client actively and conscientiously in order to satisfy Haida equipment brand consumers' needs.



    The certification

    ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, SGS, SMC, CMC, CPA, CE,CMA,IMC



    Price Concrete Compressive Strength Test Machine 2

    Price Concrete Compressive Strength Test Machine 3
