HD-A505S Paper Box Compression Tester

HD-A505S Paper Box Compression Tester

Minimum
1 SET
Delivery
15 days after order.
Model
HD-A505S
Country
China
BrandName
HD
Package
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Payment
L/C, D/P, T/T
Price
FOB, CIF


Paper Box Compression Tester


Applications:

Box Compression Tester is specialized for testing the compression performance of cartons. It is suitable for compression test, deformation test and stacking test of the corrugated cartons, honeycomb boxes an etc packages. Also, it will be usage for the compression test of containers (such as plastic drums for edible oil, mineral water), paper canisters, paper boxes, paper cans, container drums and etc.







Design Standard:

TAPPI-T804,JIS-20212,GB4857.3.4, ASTM-D642, QB/T1048, BS EN ISO 12048, GB/T4857.16, GB/T8167, GB/T8168, GB/T4857.3,GB/T4857.4



Feature:

1. Clear software interface with obvious icons, can real-time display of each test data and can monitor the test process at any time

2. Multi-purpose - customer can choose compression test or stacking test as per their requirements

3. Double Ball guide rod design. ultra-high transmission accuracy, smooth operation and high power transmission efficiency. Low failure, long life and low noise

4.Equipped with many intelligent configuration, such as limit stroke protection, overload protection, and fault prompts to ensure the safety of users' operations

5. Chinese-English bilingual test system to meet more needs;




Models of HD-A505S

Model

HD-A505S-1200

HD-A505S-1500

Capacity

20kN

50kN

Test Space (L*W*H)

1000*1200*1500 mm

1300*1500*1500 mm

Resolution

1/250,000

1/250,000

Power

AC 220V, 50 Hz, 1.5kW

AC 220V, 50 Hz, 1.5kW






Specifications:



Item

Description

Max. Force

5000kg(50KN)

Load cell

4 load cell for highest accuracy

Control system

Windows 10, RS-232 interface

Motor

Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod

Force reading

kgf, Ibf, N, KN, T etc

Load cell Resolution

1/250,000

Load Precision

within ±0.5%

Effective test area

1300*1500*1500mm

Test speed

0.01~200mm/min

Software

Mtest HD-002-A(Independent R&D)

Data display

Load, displacement, speed, loading rate and elapsed time

Safety features

E-Stop

Over-load protection

Upper and lower limit switches

Load sensor with automatic retreat




APPLICATIONS:

This instrument can make compression tests of packages (boxes) or packing and determine their piling up resistance (for storage and transport).  These tests are called B.C.T. (Box Compression Test).



The Compression Testers can operate in five ways:

1.Deformation under defined load: Test deformation under defined load of various corrugated cartons and beehive crates

2.Load under defined deformation: Test load under defined deformation of various corrugated cartons and beehive crates

3.Maximum load: test the maximum load of various corrugated cartons and beehive crates

4.Stacking test: stack test of various corrugated cartons and beehive crates

5.Cyclic test: dynamic strain according to strength & stroke





Structure



Control Panel

Drive

Four-in-one Amplifier



Circuit Board

Circuit Board

Sensor
