Thermal Conductivity Tester Laser Flash Method 1
Thermal Conductivity Tester Laser Flash Method 1

Thermal Conductivity Tester Laser Flash Method

The laser thermal conductivity meter uses a beam of laser to irradiate the sample and uses an infrared detector to measure the temperature rise on the back of the sample to calculate the thermal diffusivity of the sample.

    oops...!

    no product data.

    Go to homepage

    Product Description

    Thermal conductivity is an important physical parameter that characterizes the thermal conductivity of materials. It is one of the thermophysical properties of engineering materials, especially kiln materials.

    The laser flash method is to calculate the thermal conductivity of materials by directly measuring the thermal diffusivity, specific heat capacity and density of materials.

    The laser thermal conductivity meter uses a beam of laser to irradiate the sample and uses an infrared detector to measure the temperature rise on the back of the sample to calculate the thermal diffusivity of the sample. It is fast and convenient, and can measure the specific heat of the sample and further calculate the thermal conductivity.

    Thermal conductivity tester (laser flash method) is widely used in the testing of metals and alloys, diamonds, ceramics, graphite and carbon fibers, filled plastics, polymer materials, etc. It can also be used to test the thermal conductivity of liquids, thin films, solid electrical insulation materials, granular materials, powdered materials, and coal.


    It complies with GJB1201.1-91, ASTM D1461, ASTM E2585, GB/T 22588 and so on standards.

    Thermal Conductivity Tester Laser Flash Method

    Product Specifications

    Model 60081-HD
    Testing temperature RT~1000℃
    Heating and cooling rate 0.1~30℃/min (can be set arbitrarily) high temperature type
    Sample size Square 10*10mm~20*20mm, round <φ20mm, thickness 1~10mm (Special specifications can be customized)
    Measurable sample quantity 1~3 samples
    Test environment Vacuum degree: -0.1Mpa; Test atmosphere: inert, reducing
    Thermal diffusion coefficient range 0.01~1000mm2/s
    Thermal conductivity test range 0.1~4000W/m·K
    Pulse source Nd: YAG Laser
    Pulse energy 15J/time
    Pulse energy adjustable Yes
    Pulse interval adjustable Software setting
    Sensor Insb/MCT, air cooling
    Test sample types Solid block, low viscosity liquid, high viscosity liquid, solid powder (standard equipped with a set of clamps)
    Sample holder Graphite, SiC, Al2O3, metal (other requirements can be customized)
    Cp repeatability ±3% (most materials)
    Thermal diffusion coefficient repeatability ±2 (most materials)
    Upper computer interface USB and dedicated portable interface, which can be equipped with a network port to realize data interconnection and remote testing
    Power 1∮ AC 220V 50HZ
    Standards GJB1201.1-91, ASTM D1461, ASTM E2585, GB/T 22588, etc.

    Products Advantages

    Thermal Conductivity Tester Laser Flash Method 3
    Best Quality
    We have a number of professional suppliers which we have worked with over the 35 years, Our custom made furniture product manufacturing, Quality, delivery and Customer service.
    Thermal Conductivity Tester Laser Flash Method 4
    Reasonable Prices
    We know the market well, so we will offer you the most reasonable prices possible. You may be pleasantly surprised and will be more cost effective in the long run.
    Thermal Conductivity Tester Laser Flash Method 5
    QC Team
    We have our QC team here to help customers to check the goods throughout custom made furniture production and before loading with an AQL.
    book
    High-End Look
    When paired with a loveseat or chair, this sofa sets the scene for everyday luxury. Style tip: add a faux fur throw in white for pure delight.

    Product Characteristics

    1.The specimen and the hot and cold plates can be automatically adjusted in parallel, and the error of non-parallelism on both sides of the specimen is very small.

    2.It can realize two modes of vacuum measurement and protective atmosphere measurement (atmosphere: inert, reducing, static).

    3.It has triple temperature protection to minimize environmental thermal interference.

    4.Multiple mathematical model fitting, accurate pulse width correction and pulse energy integration, heat loss correction, built-in database;

    Through mathematical model fitting, heat loss related correction, self-calibration function of thermal conductivity and heating power can be performed.

    5.Advanced control system: it can control the temperature quickly and stably.

    6.Intelligent data processing, fully automatic thermal analysis measurement software system with WINDOWS operation interface, data analysis and report output function. Special analysis and testing software, supporting WINDOWS10 and 64-bit operating system.

    7.It can perform multi-layer contact thermal resistance analysis, and calculate parameters such as thermal resistance and thermal diffusion rate. Using standard samples with known specific heat, the specific heat can be calculated by comparison method.

    8.Integrated electronic equipment, data acquisition rate reaches 2MHz.

    9.Can be connected to a computer for fully automatic control, Chinese operating interface, automatic printing of test reports

    10.Color CCD pixels 5 million, maximum field of view 1.465*1.465mm, digital continuous zoom, motor-driven fully automatic focusing.
